Desiccant Bag Feeder

The bottle cylinder on the bottle feeding track will block the bottle transmitted by the upper equipment in the position of filling the desiccant, waiting for the desiccant to be filled, and the bottle mouth is aligned with the cutting mechanism. The stepper motor drives the bag feeding mechanism to pull the desiccant bag from the tray of the desiccant bag, the color label sensor detects the desiccant bag and controls the bag length, the scissors cut the desiccant bag and load it into the bottle, and the conveyor belt of the bottle conveying mechanism will transfer the desiccant bottle to the next device. At the same time, the medicine bottle to be filled with the desiccant bag will be filled to the position of the desiccant bag.

(1) Strong compatibility, suitable for various specifications, various materials of round, oblate, square, flat square bottles.

(2) colored label, colorless label disc bag desiccant bag;

(3) The pre-release desiccant belt design is adopted to avoid uneven bag transmission and ensure the accuracy of bag length control.

(4) The desiccant bag thickness adaptive design is adopted to avoid the occurrence of broken bags during the transfer process.

(5) High durable knife edge, accurate and reliable cutting, will not cut the desiccant bag

(6) With a number of detection alarm control functions such as no bottle does not work, fault self-test, desiccant bag does not enter the bottle, etc., to ensure the continuity of equipment operation and the accuracy of the dryer bag stuffing.

(7) The operation of the whole system, and the upper and lower processes can only be joint control, good coordination, no need for special operation, saving labor

(8) The photoelectric sensing element is produced in Taiwan, stable and durable.
