Applying
It is suitable for capsule, tablet, honey pill, candy, liquid (ointment), paste as well as irregular shape Al-al Al-plastic and paper-plastic composite sealing packing in pharmacy, healthcare, food, cosmetics, medical equipment industry etc.
Product Features
1. With manipulator towing and adjustable travel range, it can be suited for blister packing of various sizes.
2. Flat plate structure can pack special shape products, such as: elliptic shape, square shape, triangle shape, liquid, paste and syringe etc.
3. The whole procedure of feeding, forming, heat-sealing, impressing, batch number printing and cutting is accomplished automatically and continuously. The machine is small in size, with frequency inverter and ease of operation.
With touch screen operation,make the machine operation easy.
Product Parameters
|
Cutting Frequency (Times/min) |
Al-Al: 6-20 times/min Al-plastic: 10-35 times/min |
|
Max. Production Capacity (Blister/h) |
Al-Al: 1200 (According to standard plate 80×57) Al-plastic: 2100 (According to standard plate 80×57) |
|
Max. Forming Area and Depth (mm) |
Al-Al: 80× 90×14 Al-plastic: 80×115×14(max depth can enlarge) |
|
Travel Range (mm) |
20-100 (Can be customized) |
|
Air Pressure (Mpa) |
0.4-0.6 |
|
Standard Plate (mm) |
80×57 (Can be customized) |
|
Total Power |
380V/220V 50Hz 1.8kw |
|
Main Motor Power (kw) |
0.75 |
|
PVC Rigid Sheet (mm) |
0.15-0.5×120 |
|
PTP Aluminum Foil (mm) |
0.02-0.035×120 |
|
Dialysis Paper (mm) |
50-100g×120 |
|
Mould Cooling |
Tap Water or Circulating Water |
|
Overall Dimensions (mm) |
1400×460×950 (L×W×H ) |
|
Weight (kg) |
450 |
Quality Control
We have QC person stay on the production lines do to the inspection.All products must have been inspected before delivery.we do inline inspection and final inspection.
1. All raw material checked once it arrive our factory.
2. All pieces and logo and all details checked during production.
3. All packing details checked during production.
4. All production quality and packing checked on final inspection after finished.
Our Service
1. More Professional service in Packaging and printing products exporting field
2. Better manufacture ability
3. Various payment term to choose:T/T,Western Union,L/C,Paypal
4. High quality/Safe material/Competitive price
5. Small order available
6. Quickly response
7. More safe and fast transport
8. OEM design for all customers
Packaging & Shipping
Packaging: Wooden case
Shipping: by air, sea, or express
Sample lead time: 5~7 days
Delivery time: about 25~30 days after order details and production confirmed.
