Water Condensation Bead Making Machine

Working Conditions：

Ambient temperature: +15 ~ +30℃ is recommended (equipment adaptation condition: 0-40℃, specific ambient temperature should fully consider the applicable conditions for condensing beads).

Relative humidity: 30% ~ 55% no condensation (equipment adaptation conditions: 25-70%, specific use of ambient humidity should fully consider the conditions applicable to condensing beads liquid and film)

Installation conditions: indoor clean workshop with temperature and humidity control. product conditions.

packaging materials: according to the shape and gram weight requirements specified by the customer.

Storage conditions for packaging materials and semi-finished products:

(Water-soluble membrane)

Recommended temperature:+15 ~ +30℃,

Recommended humidity: 30% ~ 45%

Non-condensation storage between constant temperature and humidity, according to the requirements of the film manufacturers.

Semi-finished products storage conditions:

Recommended temperature: +15 ~+30℃,

Recommended humidity: 30% ~ 55% of the non-condensation temperature and humidity storage.

It is determined by the formula system of beads, which shall be implemented in accordance with the quality standard of beads of your company.

Water-soluble film for packaging:

Material: PVA/PVOH

Mask thickness: 75±5 m

Bottom film thickness: 75±5 m

Transparency according to the requirements of the bead manufacturer. Meet the quality acceptance standard of related products.

Applicable to specific PVA water soluble film and similar grades, applicable to film size range: bottom film width 340mm; top film width 310mm; film roll diameter less than 300mm.

This PVA film packing machine is applied to the PVA water soluble film to pack the liquid detergent automatic, which can be used for packing the sticky paste detergent and detergent powder also.

This machine adopts plc, touch screen, servo motor control, the machine operation is very stable. The machine can fill the liquid detergent or powder and form the four sides bag directly, the bag of four sides is accurate, the machine packing speed is fast and the finished bag is beautiful. The machine adopts Touch screen and PLC programmable control, photoelectric sensing, Adopt the stable reliable electrical components, make the machine run stable and easy to operate.

1. Packing bag size: can customize according to customer's inquiry
2. Packing speed: Max 160 bags / minute
3. The volume of packing: 3-50grams
4. Measurement precision: 1. 5%
5. The maximum diameter of the film: 400mm
6. The diameter of the inner hole of the packaging reel membrane: 70-80mm
7. Machine power: 10KW
8. Voltage: 220/380V/50HZ/60HZ

9. The width of the lower film: 340mm
10. The width of the upper film: 310mm
11. Sealing way: heat sealing; water sealing (optional, it need add 1500USD)
12. Machine size: 4300*1250*2150mm
13. Machine weight: 1000kg
